二维剪切波弹性成像评估慢性乙型肝炎肝纤维化临床应用指南

中华医学会超声医学分会介入超声学组弹性成像评估肝纤维化专家组

尚宏伟, 马亚楠, 路欣, 等. 肝星状细胞通过胱硫醚γ-裂解酶/硫化氢(CSE/H2S)调控肝细胞癌细胞凋亡的作用及其机制[J]. 临床肝胆病杂志, 2024, 40(11): 2238-2245. DOI: 10.12449/JCH241117.
引用本文: 尚宏伟, 马亚楠, 路欣, 等. 肝星状细胞通过胱硫醚γ-裂解酶/硫化氢(CSE/H2S)调控肝细胞癌细胞凋亡的作用及其机制[J]. 临床肝胆病杂志, 2024, 40(11): 2238-2245. DOI: 10.12449/JCH241117.
SHANG Hongwei, MA Yanan, LU Xin, et al. Role and mechanism of hepatic stellate cells in regulating the apoptosis of hepatocellular carcinoma cells through cystathionine γ-lyase/hydrogen sulfide[J]. J Clin Hepatol, 2024, 40(11): 2238-2245. DOI: 10.12449/JCH241117.
Citation: SHANG Hongwei, MA Yanan, LU Xin, et al. Role and mechanism of hepatic stellate cells in regulating the apoptosis of hepatocellular carcinoma cells through cystathionine γ-lyase/hydrogen sulfide[J]. J Clin Hepatol, 2024, 40(11): 2238-2245. DOI: 10.12449/JCH241117.

二维剪切波弹性成像评估慢性乙型肝炎肝纤维化临床应用指南

DOI: 10.3969/j.issn.1001-5256.2018.02.008
详细信息
  • 中图分类号: R512.62;R575.2

Guidelines for clinical application of two-dimensional shear wave elastography in assessment of liver fibrosis in chronic hepatitis B

  • 摘要:

    <正>HBV感染是重大传染性疾病,全球约2.4亿人感染HBV[1],我国慢性HBV感染者达9300万人,其中慢性乙型肝炎(CHB)患者约2000万例[2]。CHB也是我国导致肝硬化、肝细胞癌(HCC)的主要病因之一,分别占60%和80%[3],严重危害健康。全球每年约有65万人死于HBV感染所致的肝功能衰竭、肝硬化和HCC[4]。评估CHB患者肝纤维化程度



  • 肝星状细胞(HSC)作为肝细胞癌(HCC)微环境中最主要的窦周细胞,在HCC的发生发展中发挥了重要作用1-2。体外研究3-4表明,在HSC与HCC细胞的共培养体系中,HSC通过分泌生长因子、细胞外基质蛋白和金属基质蛋白酶诱导肿瘤细胞向恶性表型转化,同时增强肝癌细胞的侵袭与迁移能力。在皮下移植异种裸鼠肝癌模型5中发现,HSC通过促进HCC细胞增殖和抑制细胞凋亡,从而促进肿瘤生长。研究6-7还发现,HSC通过分泌血管内皮生长因子、血小板源性生长因子和转化生长因子等生长因子,促进肿瘤的血管生成。硫化氢(hydrogen sulfide, H2S)是继一氧化碳和一氧化氮后第3种重要的内源性气体信号分子,参与氧化应激、细胞增殖与凋亡、血管扩张、血管再生、炎症等多种病理生理过程8。内源性H2S由半胱氨酸和同型半胱氨酸经胱硫醚γ-裂解酶(cystathionine γ-lyase, CSE)、胱硫醚β-合酶(cystathionine β-synthase, CBS)及3-巯基丙酮酸转硫酶(3-mercapto-pyruvate sulphurtransferase, MPST)合成产生9。前期研究10发现,外源性H2S供体——NaHS,通过PI3K/Akt/mTOR信号通路诱导肝癌细胞自噬,从而促进了细胞凋亡,抑制细胞增殖与迁移。然而,在肝癌微环境中HSC是否通过H2S参与调控HCC的生物学过程尚不明确。因此,本研究通过HSC与肝癌细胞系共培养,探讨HSC通过分泌H2S参与调控肝癌细胞凋亡的作用及其机制。

    DMEM细胞培养基、胎牛血清、胰蛋白酶、青霉素-链霉素、CSE抑制剂——炔丙基甘氨酸(propargylglycine, PPG)及JNK/JunB抑制剂——SP600125试剂购自赛默飞世尔科技(中国)有限公司;H2S检测ELISA试剂盒购自南京金益柏生物科技有限公司;RNA提取、逆转录及SYBR等RT-qPCR试剂购自宝日医生物技术(北京)有限公司;Transwell小室购自美国康宁公司;CCK-8试剂盒购自美国Abmole奥默生物公司;Annexin V-FITC/PI细胞凋亡试剂盒购自上海翊圣生物科技有限公司;人源β- actin、GAPDH、JNK、JunB、p-JNK/JunB抗体和二抗、ChIP试剂盒购自美国Cell Signaling technology公司;肿瘤坏死因子超家族成员-14(tumor necrosis factor superfamily member-14,TNFSF14)多克隆抗体购于美国Affinity Biosciences公司。

    肝星状细胞系(LX-2)及肝癌细胞系(HepG2、PLC/PRF/5),用含10%胎牛血清及1%的青霉素-链霉素混合液的DMEM培养基,置于37 ℃,5%(体积分数)CO2恒温细胞孵育箱内培养。Transwell小室建立共培养体系,上室接种LX-2,下室接种HepG2或PLC/PRF/5,按照说明书操作。所有细胞实验重复3次。

    LX-2产生的H2S浓度及NaHS释放的H2S,按照说明书进行操作。在酶标板对应的孔中分别加入标品及待检测的LX-2培养上清液和NaHS,随后进行孵育和洗板,加入显色液37 ℃孵育15 min,加入终止液终止反应。酶标仪450 nm波长测定,根据标准曲线,计算所测样本中H2S浓度。

    Trizol法提取总RNA。取1 μg总RNA,按照Takara逆转录试剂盒合成cDNA,SYBR Green Master Mix说明书配置20 μL RT PCR体系,ABI 7500进行RT-q PCR。所需的引物序列见表1。LX-2与HepG2共培养(LX-2共培养组)、NaHS处理HepG2(NaHS处理组)及对照组(单独HepG2培养)提取的HepG2细胞总RNA送至北京诺禾致源科技股份有限公司进行转录组二代测序分析,对差异基因[以|log2(fold change)|≥1为差异表达基因的标准]进行聚类分析和Veen分析。

    表  1  RT-qPCR和ChIP-PCR所需要的引物序列
    Table  1.  Primers for Real-Time PCR and ChIP-PCR
    项目 寡核苷酸序列
    RT-qPCR引物
    TNFSF14 F:5'-CGTGAGACCTTCGCTCTTGTAT-3'
    R:5'-CCCTCAGTGTTTGTGGTGGAT-3'
    CSE F:5'-AAGACGCCTCCTCACAAGGT-3'
    R:5'-ATATTCAAAACCCGAGTGCTGG-3'
    GAPDH F:5'-TGAAGGTCGGAGTCAACGGA-3'
    R:5'-CCTGGAAGATGGTGATGGGAT-3'
    CBS

    F:5'-AATGGTGACGCTTGGGAA-3'

    R:5'-TGAGGCGGATCTGTTTGA-3'

    MPST

    F:5'-GACCCCGCCTTCATCAAG-3'

    R:5'-CATGTACCACTCCACCCA-3'

    ChIP-qPCR引物
    TNFSF14 F:5'-TTGTTCATTGCTGCATCCCC-3'
    R:5'-CTCCTCTTCTTCCGGTACCC-3'
    下载: 导出CSV
    | 显示表格

    取LX-2共培养组及NaHS处理组的HepG2细胞,PBS清洗2次,随后在10 cm2培养皿中加入1 mL RAPI裂解液,冰上裂解20 min,转移裂解液到EP管中,4 ℃,12 000×g离心30 min,上清即为细胞总蛋白。BCA试剂盒对提取的蛋白进行定量分析,加入对应体积的蛋白上样缓冲液后置于100 ℃金属浴5 min,使蛋白变性,用于后续WB检测。SDS-PAGE胶用于分析所提取的蛋白,取20 μg蛋白上样电泳,转膜,牛奶封闭,随后加入对应的抗体4 ℃孵育过夜,将孵育好的膜放到对应的二抗中,室温孵育1 h后,加入化学发光液测定和分析。

    将生长状态良好的细胞接种在96孔板,LX-2分别与HepG2、PLC/PRF/5共培养1、2、3、4天,单独HepG2、PLC/PRF/5培养分别作为对照组。按照说明书,每孔加入10 μL CCK-8试剂,随后置于37 ℃培养箱内孵育1 h后,酶标仪450 nm测定吸光度值。细胞活力计算:细胞活力(%)=[A450(样本-空白)]/[A450(对照-空白)]×100%。

    将处理好的细胞制备成为单细胞悬液,按照Annexin V-FITC/PI细胞凋亡试剂盒说明书,加入5 μL Annexin V孵育,再加入5 μL PI避光孵育,FACS流式细胞仪(BD公司)进行检测。

    细胞均匀接种到已放入无菌盖玻片的24孔板中,NaHS处理HepG2细胞0、1、2、8、24 h。取处理好的细胞,加入1 mL 4%多聚甲醛固定,随后进行透膜处理,加入1% BSA稀释抗体p-JunB(1∶500),4 ℃孵育过夜。1% BSA稀释FITC标记的荧光二抗(1∶500)避光条件下,室温孵育1 h。DAPI染核及封片,荧光显微镜下采集图像,Image J软件分析目的蛋白平均免疫荧光强度。

    LX-2分别与HepG2和PLC/PRF/5共培养,以及NaHS分别处理HepG2和PLC/PRF/5细胞后,ChIP方法测定p-JunB与TNFSF14启动子结合力。WB测定HepG2和PLC/PRF/5细胞核中p-JunB表达,应用4',6-二脒基-2-苯基吲哚(4',6-diamidino-2-phenylindole,DAPI)对细胞核DNA染色(蓝色)和FITC标记的抗体测定细胞核p-JunB表达(绿色)。LX-2与NaHS处理后的HepG2和PLC/PRF/5细胞用4%多聚甲醛固定10 min,核酸酶将DNA特异性的消化为DNA片段,随后加入JunB、p-JunB抗体,从而特异性的富集目的蛋白质和DNA复合体,通过对复合体进行富集纯化,收集DNA用于PCR检测。

    采用SPSS 21.0统计软件进行数据分析。计量资料以x¯±s表示,两组间比较采用成组t检验;多组间比较采用单因素方差分析或重复测量方差分析,进一步两两比较采用Dunnett-t检验。P<0.05为差异有统计学意义。

    LX-2培养上清液中H2S浓度随着时间延长逐渐增加[(22.89±0.08)pg/mL vs (28.29±0.15)pg/mL vs (36.19±1.90) pg/mL,F=79.63,P<0.05](图1a)。LX-2中CSE mRNA水平显著高于CBS mRNA和MPST mRNA(1.008±0.13 vs 0.320±0.014 vs 0.05±0.02, F=80.84,P<0.05)(图1b)。在LX-2中加入不同剂量PPG后,随着PPG浓度增加,H2S浓度下降(P<0.05)(图1c)。PPG特异性、浓度依赖性的降低CSE mRNA及蛋白水平(图1d、e)。

    注: a,LX-2细胞产生H2S的浓度;b,CSE、CBS和MPST的mRNA在LX-2细胞中的表达倍数;c,PPG处理后LX-2产生H2S的浓度;d,CSE的mRNA表达;e,CSE蛋白的表达水平。
    图  1  LX-2通过CSE途径产生H2S
    Figure  1.  LX-2 produce H2S mainly via the CSE

    LX-2分别与HepG2、PLC/PRF/5共培养,随着培养时间延长,HepG2(87.48%±0.82% vs 70.48%±0.641% vs 52.89%±0.57% vs 45.20%±0.69%,F=1 517.13,P<0.001)和PLC/PRF/5(92.41%± 0.48% vs 74.10%±0.73% vs 53.70%±0.60% vs 44.00%± 0.27%,F=2 626.21,P<0.001)细胞活力降低(图2a、b);凋亡增加(HepG2:12.88%±0.64% vs 15.5%±0.16% vs 18.43%±0.37% vs 13.01%±0.58%,F=142.15,P<0.001;PLC/PRF/5:8.51±0.05 vs 12.80±0.33 vs 15.59±0.21 vs 10.72±0.30,F=676.40,P<0.001),第3天最显著(图2c、d)。

    注: a,HepG2细胞活力;b,PLC/PRF/5细胞活力;c,HepG2细胞凋亡;d,PLC/PRF/5细胞凋亡。a、c,对照组为单独HepG2培养;b、d,对照组为单独PLC/PRF/5培养。与第1天比较,*P<0.05。
    图  2  LX-2与肝癌细胞系共培养对肝癌细胞活力及凋亡的影响
    Figure  2.  Effect of LX-2 co-culture with hepatoma cell on viability and apoptosis

    LX-2与HepG2共培养及NaHS处理HepG2后,转录组测序显示分别上调1 047和1 183个基因,共同上调659个基因;分别下调997和1 144个基因,共同下调342个基因(图3a)。其中,30个变化最大的基因,包括TGM2、PDE2A、AQP7P1、SOCS3、B3GNT3、LGALS7B、CPNE7、TCAF2、AXL、CD3D、BEAN1、KIF26B、SLC1A7、TFF1、IGFBP3、ADAMTS16、ACTA1、SLC2A5、SERPINE2、KCNMB4、LSP1、A4GALT、TNFSF14、NPPB、MUC5B、NKAIN4、TRAF5、PFKP、EHD2、MTMR11(图3b)。选择促凋亡基因TNFSF14进行分析,与对照组相比,NaHS处理组TNFSF14基因增加约2.8倍,LX-2共培养组TNFSF14基因增加约2倍(P<0.05)(图3c)。

    注: a,聚类分析;b,差异倍数值变化最大的30个差异基因;c,TNFSF14基因表达变化。对照组,单独HepG2培养。
    图  3  RNA-seq分析内源性和外源性H2S对HepG2细胞转录基因的影响
    Figure  3.  RNA-seq to analyse the transcriptome of endogenous and exogenous of H2S on HepG2

    ChIP实验发现,与对照组相比,NaHS处理的HepG2和PLC/PRF/5细胞中p-JunB与TNFSF14基因转录调控区域结合增加(图4a);p-JunB定位于细胞核中,NaHS作用1 h荧光强度开始升高,8 h达到高值(图4b);且与WB结果一致(图4c)。PPG干预后,HepG2和PLC/PRF/5胞核蛋白p-JunB表达明显下降(图4d);经SP600125(JNK/JunB抑制剂)处理后,显示JNK/JunB-TNFSF14信号通路被抑制。NaHS处理也显示了相似结果(图4e)。延长NaHS处理时间,细胞核p-JunB表达增加,但JunB表达无明显变化。结果提示,LX-2和NaHS通过释放H2S,激活JNK/JunB信号通路调控TNFSF14基因转录。

    注: a,ChIP显示,在HepG2和PLC/PRF/5细胞中,p-JunB与TNFSF14启动子结合力增加;b,NaHS分别处理HepG2和PLC/PRF/5 0、1、2、8、24 h后,HepG2和PLC/PRF/5细胞核中p-JunB表达及核转位,DAPI(蓝色)和FITC(绿色)分别为对细胞核DNA及p-JunB进行染色;c,NaHS不同处理时间后,HepG2和PLC/PRF/5细胞核与细胞质中p-JunB的表达;d,NaHS处理组和LX-2共培养组HepG2及PLC/PRF/5细胞的p-JunB蛋白变化;e,PPG和SP600125抑制了H2S及NaHS对HepG2与PLC/PRF/5中JNK/p-JNK、JunB/p-JunB、TNFSF14蛋白水平。
    图  4  内源性H2S和NaHS通过激活JNK/JunB信号通路调控TNFSF14转录
    Figure  4.  Endogenous H2S and NaHS upregulated TNFSF14 via JNK/JunB signaling pathway

    第3个重要的内源性气体信号分子H2S自1992年被发现,较多研究11-12证实了H2S及其合成酶的多种功能,参与了血管扩张、血管生成、炎症免疫、氧化应激和细胞凋亡与自噬的调控等过程,在肿瘤和非肿瘤性疾病,特别是心血管疾病的病理生理中具有重要作用。因此,H2S及其合成酶可能是治疗的靶点。但是,CSE/H2S在肝癌发生发展中的作用研究较少13。由肝细胞及肝窦周细胞,包括HSC、肝窦内皮细胞、Kuffer细胞、肝癌细胞和细胞外基质等组成的复杂肿瘤微环境(tumor microenvironment, TME)中,HSC及信号分子H2S促进肝癌细胞凋亡的机制尚未阐明14。本研究发现,HSC主要通过CSE产生信号分子H2S,激活了肝癌细胞中的JNK/JunB信号通路,上调TNFSF14基因,TNFSF14表达增加,从而促进了肝癌细胞的凋亡,发挥抗肿瘤作用。Han等15发现,HepG2中TNFSF14下调Bcl-2和survivin,通过线粒体及p53独立途径,诱导肝癌细胞凋亡。体外研究16表明,在HepG2和SMMC-7721细胞中,TNFSF14与LT-βR结合,激活caspase-9和caspase-3,抑制STAT3磷酸化下调Bcl-XL表达,进而诱导肝癌细胞凋亡,提示线粒体途径也是TNFSF14诱导细胞凋亡的关键因素。由此可见,TNFSF14通过线粒体凋亡途径和死亡受体凋亡途径等,促进肝癌细胞凋亡。此外,TNFSF14还表达于免疫细胞,如活化T淋巴细胞,未成熟树突状细胞和活化自然杀伤细胞,TNFSF14信号转导对T淋巴细胞激活和诱导细胞凋亡具有重要作用17。TNFSF14也通过激活抗肿瘤免疫效应,间接杀伤肿瘤细胞和触发肿瘤细胞凋亡,表现出强大的免疫抗肿瘤活性,在多种不同的肿瘤中发挥抗瘤作用18。因此推测,在肝癌微环境中,H2S通过激活肝癌细胞中凋亡基因TNFSF14表达及多种细胞凋亡信号途径,促进肝癌细胞凋亡。

    TNFSF14诱导肝癌细胞凋亡的分子机制尚不清楚。本研究ChIP实验证明,无论是在HepG2还是在PLC/PRF/5中,转录因子p-JunB均可与TNFSF14基因的转录调控区域结合,且H2S增强了p-JunB与TNFSF14基因启动子的结合能力。H2S生成酶CSE抑制剂——PPG和p-JNK抑制剂SP600125,均显著抑制了H2S对JNK/JunB信号通路的激活,导致TNFSF14表达降低。上述结果提示H2S在调节肝癌细胞TNFSF14表达中具有重要作用。细胞免疫荧光和WB也证明了外源性H2S供体NaHS及HSC合成的内源性H2S,促进了肝癌细胞p-JunB的表达及核转位。JunB作为Jun家族的重要成员之一,是转录因子AP-1(转录激活蛋白-1)的主要成分,对各种刺激如辐射、应激及生长信号等作出生理或病理应答,参与细胞增殖与分化、转化、凋亡、炎症等过程,在肿瘤的形成、转移和侵袭中发挥重要作用19。也有研究20发现,JNK/JunB促进HepG2凋亡并抑制了其增殖与侵袭能力。因此,本研究首次阐明了TNFSF14启动子的转录活性受到转录因子JunB的调控,H2S可激活转录因子JunB,促进p-JunB的核转位,进而上调肝癌细胞凋亡基因TNFSF14。CSE/H2S可能是防治HCC具有潜力的新靶点。

    总之,在TME中活化HSC合成分泌信号分子H2S,通过激活肝癌细胞中的JNK/JunB-TNFSF14信号通路,从而促进肝癌细胞凋亡、抑制肿瘤细胞活力,可能是HSC在TME中调节肝癌细胞生物学功能的新机制之一。

  • [1]OTT JJ, STEVENS GA, GROEGER J, et al.Global epidemiology of hepatitis B virus infection:new estimates of age-specific HBs Ag seroprevalence and endemicity[J].Vaccine, 2012, 30 (12) :2212-2219.
    [2]LIU J, ZHANG S, WANG Q, et al.Seroepidemiology of hepatitis B virus infection in 2 million men aged 21-49 years in rural China:a population-based, cross-sectional study[J].Lancet Infect Dis, 2016, 16 (1) :80-86.
    [3]WANG FS, FAN JG, ZHANG Z, et al.The global burden of liver disease:the major impact of China[J].Hepatology, 2014, 60 (6) :2099-2108.
    [4]LOZANO R, NAGHAVI M, FOREMAN K, et al.Global and regional mortality from 235 causes of death for 20 age groups in 1990and 2010:a systematic analysis for the Global Burden of Disease Study 2010[J].Lancet, 2012, 380 (9859) :2095-2128.
    [5]Chinese Society of Hepatology and Chinese Society of Infectious Diseases, Chinese Medical Association.The guideline of prevention and treatment for chronic hepatitis B:a 2015 update[J].J Clin Hepatol, 2015, 31 (12) :1941-1960. (in Chinese) 中华医学会肝病学分会, 中华医学会感染病学分会.慢性乙型肝炎防治指南 (2015年更新版) [J].临床肝胆病杂志, 2015, 31 (12) :1941-1960.
    [6] European Association for the Study of the Liver.EASL 2017 Clinical Practice Guidelines on the management of hepatitis B virus infection[J].J Hepatol, 2017, 67 (2) :370-398.
    [7]SHIHA G, IBRAHIM A, HELMY A, et al.Asian-Pacific association for the study of the liver (APASL) consensus guidelines on invasive and non-invasive assessment of hepatic fibrosis:a 2016 update[J].Hepatol Int, 2017, 11 (1) :1-30.
    [8]BAMBER J, COSGROVE D, DIETRICH C, et al.EFSUMB guidelines and recommendations on the clinical use of ultrasound elastography.Part 1:basic principles and technology[J].Ultraschall Med, 2013, 34 (2) :169-184.
    [9]COSGROVE D, PISCAGLIA F, BAMBER J, et al.EFSUMB guidelines and recommendations on the clinical use of ultrasound elastography.Part 2:clinical applications[J].Ultraschall Med, 2013, 34 (3) :238-253.
    [10] DIETRICH CF, BAMBER J, BERZIGOTTI A, et al.EFSUMB guidelines and recommendations on the clinical use of liver ultrasound elastography, Update 2017 (Long Version) [J].Ultraschall Med, 2017, 38 (4) :e16-e47.
    [11]DIETRICH CF, BAMBER J, BERZIGOTTI A, et al.EFSUMB guidelines and recommendations on the clinical use of liver ultrasound elastography, Update 2017 (Short Version) [J].Ultraschall Med, 2017, 38 (4) :377-394.
    [12]SHIINA T, NIGHTINGALE KR, PALMERI ML, et al.WFUMB guidelines and recommendations for clinical use of ultrasound elastography:Part 1:basic principles and terminology[J].Ultrasound Med Biol, 2015, 41 (5) :1126-1147.
    [13]FERRAIOLI G, FILICE C, CASTERA L, et al.WFUMB guidelines and recommendations for clinical use of ultrasound elastography:Part 3:liver[J].Ultrasound Med Biol, 2015, 41 (5) :1161-1179.
    [14]BARR RG, FERRAIOLI G, PALMERI ML, et al.Elastography assessment of liver fibrosis:society of radiologists in ultrasound consensus conference statement[J].Radiology, 2015, 276 (3) :845-861.
    [15]ZENG J, ZHENG J, HUANG Z, et al.Comparison of 2-D shear wave elastography and transient elastography for assessing liver fibrosis in chronic hepatitis B[J].Ultrasound Med Biol, 2017, 43 (8) :1563-1570.
    [16]HERRMANN E, de LDINGHEN V, CASSINOTTO C, et al.Assessment of biopsy-proven liver fibrosis by 2D-shear wave elastography:an individual patient data based meta-analysis[J].Hepatology, 2018, 67 (1) :260-272.
    [17]THIELE M, DETLEFSEN S, SEVELSTED MLLER L, et al.Transient and 2-dimensional shear-wave elastography provide comparable assessment of alcoholic liver fibrosis and cirrhosis[J].Gastroenterology, 2016, 150 (1) :123-133.
    [18]YONEDA M, THOMAS E, SCLAIR SN, et al.Supersonic shear imaging and transient elastography with the XL probe accurately detect fibrosis in overweight or obese patients with chronic liver disease[J].Clin Gastroenterol Hepatol, 2015, 13 (8) :1502-1509.
    [19]CASSINOTTO C, LAPUYADE B, MOURIES A, et al.Non-invasive assessment of liver fibrosis with impulse elastography:comparison of Supersonic Shear Imaging with ARFI and Fibro Scan (R) [J].J Hepatol, 2014, 61 (3) :550-557.
    [20]LEUNG VY, SHEN J, WONG VW, et al.Quantitative elastography of liver fibrosis and spleen stiffness in chronic hepatitis B carriers:comparison of shear-wave elastography and transient elastography with liver biopsy correlation[J].Radiology, 2013, 269 (3) :910-918.
    [21]BAVU E, GENNISSON JL, COUADE M, et al.Noninvasive in vivo liver fibrosis evaluation using supersonic shear imaging:a clinical study on 113 hepatitis C virus patients[J].Ultrasound Med Biol, 2011, 37 (9) :1361-1373.
    [22]GUYATT GH, OXMAN AD, VIST GE, et al.GRADE:an emerging consensus on rating quality of evidence and strength of recommendations[J].BMJ, 2008, 336 (7650) :924-926.
    [23]GERSAK MM, BADEA R, LENGHEL LM, et al.Influence of food Intake on 2-D shear wave elastography assessment of liver stiffness in healthy subjects[J].Ultrasound Med Biol, 2016, 42 (6) :1295-1302.
    [24]MEDERACKE I, WURSTHORN K, KIRSCHNER J, et al.Food intake increases liver stiffness in patients with chronic or resolved hepatitis C virus infection[J].Liver Int, 2009, 29 (10) :1500-1506.
    [25]ARENA U, LUPSOR-PLATON M, STASI C, et al.Liver stiffness is influenced by a standardized meal in patients with chronic hepatitis C virus at different stages of fibrotic evolution[J].Hepatology, 2013, 58 (1) :65-72.
    [26]BERZIGOTTI A, de GOTTARDI A, VUKOTIC R, et al.Effect of meal ingestion on liver stiffness in patients with cirrhosis and portal hypertension[J].PLo S One, 2013, 8 (3) :e58742.
    [27]GERSAK MM, SORANTIN E, WINDHABER J, et al.The influence of acute physical effort on liver stiffness estimation using Virtual Touch Quantification (VTQ) .Preliminary results[J].Med Ultrason, 2016, 18:151-156.
    [28]FERRAIOLI G, TINELLI C, ZICCHETTI M, et al.Reproducibility of real-time shear wave elastography in the evaluation of liver elasticity[J].Eur J Radiol, 2012, 81 (11) :3102-3106.
    [29]SUH CH, KIM SY, KIM KW, et al.Determination of normal hepatic elasticity by using real-time shear-wave elastography[J].Radiology, 2014, 271 (3) :895-900.
    [30]HUDSON JM, MILOT L, PARRY C, et al.Inter-and intra-operator reliability and repeatability of shear wave elastography in the liver:a study in healthy volunteers[J].Ultrasound Med Biol, 2013, 39 (6) :950-955.
    [31]ZENG J, LIU GJ, HUANG ZP, et al.Diagnostic accuracy of twodimensional shear wave elastography for the non-invasive staging of hepatic fibrosis in chronic hepatitis B:a cohort study with internal validation[J].Eur Radiol, 2014, 24 (10) :2572-2581.
    [32]ZHENG J, GUO H, ZENG J, et al.Two-dimensional shear-wave elastography and conventional US:the optimal evaluation of liver fibrosis and cirrhosis[J].Radiology, 2015, 275 (1) :290-300.
    [33]HUANG Z, ZHENG J, ZENG J, et al.Normal liver stiffness in healthy adults assessed by real-time shear wave elastography and factors that influence this method[J].Ultrasound Med Biol, 2014, 40 (11) :2549-2555.
    [34]WANG CZ, ZHENG J, HUANG ZP, et al.Influence of measurement depth on the stiffness assessment of healthy liver with realtime shear wave elastography[J].Ultrasound Med Biol, 2014, 40 (3) :461-469.
    [35]FERRAIOLI G, TINELLI C, DAL BELLO B, et al.Accuracy of real-time shear wave elastography for assessing liver fibrosis in chronic hepatitis C:a pilot study[J].Hepatology, 2012, 56 (6) :2125-2133.
    [36]HUANG ZP, ZHANG XL, ZENG J, et al.Study of detection times for liver stiffness evaluation by shear wave elastography[J].World J Gastroenterol, 2014, 20 (28) :9578-9584.
    [37]PROCOPET B, BERZIGOTTI A, ABRALDES JG, et al.Real-time shear-wave elastography:applicability, reliability and accuracy for clinically significant portal hypertension[J].J Hepatol, 2015, 62 (5) :1068-1075.
    [38]THIELE M, MADSEN BS, PROCOPET B, et al.Reliability criteria for liver stiffness measurements with real-time 2D shear wave elastography in different clinical scenarios of chronic liver disease[J].Ultraschall Med, 2017, 38 (6) :648-654.
    [39]SPOREA I, GRDINARU-TA爦CU O, BOTA S, et al.How many measurements are needed for liver stiffness assessment by 2D-shear wave elastography (2D-SWE) and which value should be used:the mean or median?[J].Med Ultrason, 2013, 15 (4) :268-272.
    [40]SPOREA I, BOTA S, JURCHIS A, et al.Acoustic radiation force impulse and supersonic shear imaging versus transient elastography for liver fibrosis assessment[J].Ultrasound Med Biol, 2013, 39 (11) :1933-1941.
    [41]ZENG J, ZHENG J, HUANG ZP, et al.The comparative study of two-dimensional shear wave elastography for assessing hepatic fibrosis in chronic hepatitis B using different taking value methods[J].Chin J Ultras Med, 2016, 32 (8) :717-720. (in Chinese) 曾婕, 郑剑, 黄泽萍, 等.二维剪切波成像诊断慢性乙型肝炎肝纤维化不同取值方法的对比研究[J].中国超声医学杂志, 2016, 32 (8) :717-720.
    [42]POYNARD T, MUNTEANU M, LUCKINA E, et al.Liver fibrosis evaluation using real-time shear wave elastography:applicability and diagnostic performance using methods without a gold standard[J].J Hepatol, 2013, 58 (5) :928-935.
    [43]YOON JH, LEE JM, JOO I, et al.Hepatic fibrosis:prospective comparison of MR elastography and US shear-wave elastography for evaluation[J].Radiology, 2014, 273 (3) :772-782.
    [44]ZHUANG Y, DING H, ZHANG Y, et al.Two-dimensional shear-wave elastography performance in the noninvasive evaluation of liver fibrosis in patients with chronic hepatitis B:comparison with serum fibrosis indexes[J].Radiology, 2017, 283 (3) :873-882.
    [45]PISCAGLIA F, SALVATORE V, MULAZZANI L, et al.Ultrasound shear wave elastography for liver disease.A critical appraisal of the many actors on the stage[J].Ultraschall Med, 2016, 37 (1) :1-5.
    [46]COCO B, OLIVERI F, MAINA AM, et al.Transient elastography:a new surrogate marker of liver fibrosis influenced by major changes of transaminases[J].J Viral Hepat, 2007, 14 (5) :360-369.
    [47]MILLONIG G, REIMANN FM, FRIEDRICH S, et al.Extrahepatic cholestasis increases liver stiffness (Fibro Scan) irrespective of fibrosis[J].Hepatology, 2008, 48 (5) :1718-1723.
    [48]MILLONIG G, FRIEDRICH S, ADOLF S, et al.Liver stiffness is directly influenced by central venous pressure[J].J Hepatol Elsevier, 2010, 52 (2) :206-210.
    [49]BARDOU-JACQUET E, LEGROS L, SORO D, et al.Effect of alcohol consumption on liver stiffness measured by transient elastography[J].World J Gastroenterol, 2013, 19 (4) :516-522.
